WL-C-3.5

Space-Saving & Budget-Friendly: Glass-Aluminum Cabin Elevator

Say goodbye to bulky elevators—this cabinet-only model combines a transparent glass cabin with a sturdy aluminum alloy frame, blending sleek design with practicality.
Its biggest strengths is ultra-compact size and minimal footprint. Far slimmer than traditional elevators, it fits effortlessly into tight spots: a villa's corner, a small shop, or a home renovation where space is precious—no more wasting valuable area for vertical movement. Plus, it's remarkably affordable. By focusing only on the essential cabin (ditching redundant components), it slashes unnecessary costs while keeping performance reliable.
For a no-fuss, budget-friendly elevator that maximizes space, this glass-aluminum cabin option is the smart pick.
Model WL-C-3~15
Capacity 350-500kg
Lifting floors 2-5 floors
Platform size Standard 1200*1000mm or customizable
Voltage 220v single phase
Drive system Hydraulic system/ Traction system
Material The tempered glass with aluminum alloy frame cabinet
Entrance 1 or 2 sided
Pit 10cm depth or directly install on the ground
inquiry
Detail

The interior finished style

The cabin of elevator combines a robust aluminum alloy frame with premium tempered glass—a perfect blend of safety, style,

and functionality for residential spaces.The corrosion-resistantaluminum frame ensures structural stability while maintaining

a sleek, space-saving profile, avoiding the clunkiness of traditional metal enclosures. Paired with shatterproof tempered glass,

it creates an open, lightfilled interior that amplifies natural light and visually expands the cabin, making rides feel airy instead

of confined. The transparent (or optional frosted/tinted) glass also keeps you connected to your home’s surroundings,

adding a sense of warmth to vertical transport.




Why choose us
Be Customizable
​all the lifts are designed customizable according to customers' space,mini space is 1m*1m
No Pit / No Machine Room
Ready-made and all-inclusive lift concept with a pit of only 10 cm and just 1.8 m headroom to ensure a fast and easy installation.
Safety System
With a variety of safety measures to ensure the safety of passengers taking the elevator
Run Smoothly
​It runs smoothly ,comfortably and is very quiet, so you won't be disturbed even when talking or taking a break.
Energy Efficiency
Powered by 220V single-phase electricity, this elevator stands out with exceptional energy efficiency—keeping your energy costs impressively low.
Easy Installation
Expert technicians craft 3D installation diagrams – guiding you step by step for a hassle-free setup, ensuring perfect assembly with zero stress.
Lift Safety
Limit Switch: Absolute Over-Travel Protection
Equipped with a high-precision  limit  switch ,  the  elevator  is  fully  safe guarded  agains tovertraveling  to  the  top ,  eliminating  any  risk of  upper-end  malfunctions  and ensuring most  operational safety.
Silent Pump Station: Quiet, Efficient &Leak-Proof Performance
Boasting are nowned-brand  silent  pump  station  paired  with  a  premium  oil  cylinder ,  it achieves  zero  oil  leakage,  delivers  top-tier  working  efficiency,  and  generatesrobust  pressure—blending  powerful  performance  with  ultra-quiet  operation  for  adisturbance-free  environment.
High-Strength Plate Chain: Uncompromising Anti-Fall Security
Adopting industrial-grade 16A high-strength  plate chains,  the  elevator  car  is  firmly secured.  This heavy-duty  chain  system  completely  eliminates  the  risk  off alling,  providing  rock-solid  stability  you  can  trust.
Electric Lock: Dual Safety for Landing Doors
The landing door features an innovative "door-open power-off" function—when  the  dooris  ajar,  the  elevator  halts  immediately  to  prevent  accidents.  Plus,  anelectromagnetic  lock  engages  automatically  during  operation,  locking  the landing  door  tightly  for double  security.
Backup System: Dual Assurance forUninterrupted Use
Equipped with both a reliable backup power supply and a mechanical knob lowering system. Even inunexpected power outages, you’re guaranteed safe, smooth descent—no panic, only peace of mind.
Light Curtain: Intelligent Anti-Pinch Protection
Fitted with asensitive light curtain safety device. The moment a passenger’s hands, feet, orany object extends outside the car, the elevator stops instantly, effectively avoiding pinch risks and safeguarding every ride.
FAQ
How to ensure the accuracy of the elevator dimensions?

Our professional technical and design team will create customized elevator drawings based on your actual installation space. Production will only commence after you have confirmed and approved the drawings, ensuring precise dimensional fit from the very start.


How to purchase this elevator?

- After confirming the elevator details and price, pay a 30% deposit—we will immediately initiate both the drawing design and production processes.

- Once production is completed, settle the balance. We will arrange for delivery and have the elevator shipped directly to your doorstep, so you don’t need to worry about logistics at all.



How to install this elevator?

- Upon placing your order, we will provide a detailed step-by-step installation guide video to walk you through the entire installation process.

- Our professional technicians offer free online guidance throughout the installation.

- A paid on-site installation service is also available for your convenience, which you can opt for based on your needs.

How to maintain the elevator? What about the warranty policy and service life?

- Maintenance: It’s straightforward—simply apply machine butter to the chain at regular intervals for lubrication.

- Warranty & After-sales Service: We provide a 2-year warranty. During the warranty period, replacement parts will be shipped to you free of charge. Additionally, we offer lifetime technical support.

- Service Life: With proper use and regular maintenance, the elevator can serve for 10 to 15 years.
